| Brand Name : | HuanYu Dream |
| Model Number : | HY-1311W60D3-3W |
| Certification : | Rohs |
| Price : | Negotiable |
| Payment Terms : | T/T, Paypal,Ali Pay |
| Supply Ability : | 500000pcs/Day |
| Delivery Time : | 7-9 Work Days |
1313 1919 2828 COB LED Chip 3W 10W 100W COB LED With High Brigheness
Product Description:
COB LED Chip is an Ideal Solution for Indoor and Outdoor Lighting Applications. It Features High Reliability, High CRI, and High Luminous Efficacy. It Provides Excellent Color Consistency with SDCM in 3steps or 5steps, and it also has a long lifespan up to 50,000 hours and a 3-year warranty. Moreover, the package of COB LED Chip is customizable so that it can meet the needs of customers. Therefore, it is an ideal choice for professional lighting projects.
| S/N. | Size (MM) | Light Area (mm) | Power (W) | Voltage (V) | Current (mA) | Part No. |
1 | 13*13 | φ11 | 3W | 9-10V | 300mA | HY01311-60D3-0303B |
| 2 | 5W | 15-17V | HY01311-60D3-0503B | |||
| 3 | 7W | 21-23V | HY01311-60D3-0702B | |||
| 4 | 10W | 30-34V | HY01311-30D3-1002B | |||
| 5 | 7-12W | 36-39V | HY01311-30D3-1202B | |||
| 6 | 15W | 45-45V | HY01311-30D3-1502B | |||
| 7 | 18W | 54-58V | HY01311-30D3-1802B | |||
| 8 | 12-18W | 36-39V | 450mA | HY01311-30D3-1203B | ||
| 9 | 20-24W | 36-39V | 600mA | HY01311-30D3-1204B | ||
| 10 | 19*19 | φ17 | 12W | 36-39V | 300mA | HY01917-57D3-1202B |
| 11 | 12-18W | 450mA | HY01917-57D3-1203B | |||
| 12 | 18-24W | 600mA | HY01917-57D3-1204B | |||
| 13 | 24-30W | 750mA | HY01917-57D3-1205B | |||
| 14 | 30-36W | 900mA | HY01917-57D3-1206B | |||
| 15 | 36-42W | 1050mA | HY01917-57D3-1207B | |||
| 16 | 42-48W | 1200mA | HY01917-57D3-1208B | |||
| 17 | 28*28 | φ25 | 24-30W | 36-39V | 750mA | HY02823-57D3-1205B |
| 18 | 30-36W | 900mA | HY02823-57D3-1206B | |||
| 19 | 36-42W | 1050mA | HY02823-57D3-1207B | |||
| 20 | 42-48W | 1200mA | HY02823-57D3-1208B | |||
| 21 | 48-60W | 1500mA | HY02823-57D3-1210B | |||
| 22 | 80W | 2200mA | HY02823-57D3-1215B | |||
| 23 | 100W | 2800mA | HY02823-57D3-1219B | |||
| 24 | 38*38 | φ34 | 200W | 54-57V | 3700mA | HY03834-30D3-1826B |
| 25 | 300W | 5700mA | HY03834-30D3-1838B | |||
| 26 | 50*50 | φ47 | 500W | 72-76V | 7200mA | HY05047-30D3-2448B |
COB LED Chips Picture
 |  |
| 1313 COB LED Chip | 1919 COB LED Chip |
 |  |
| 2828 COB LED Chip | 3838 COB LED Chip |
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-3 days, mass production time needs 3-7 days according to the order quantity .
Q3. Do you have any MOQ limit for led light order?What's the Payment way ?
A: MOQ is 100pcs for each model. We accept T/T Paypal and Western Union three ways payment.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.Secondly, during the guarantee period, we will send new.
|
|
