    0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle

    Ask Lasest Price
    Brand Name : HuanYu Dream
    Model Number : HY-3528 Green
    Certification : RoHS
    Price : Negotiable
    Payment Terms : T/T, Paypal,Ali Pay
    Supply Ability : 500kpcs/Day
    Delivery Time : 7-9 Work Days
    • Product Details
    • Company Profile

    0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle

    3528 Smd Led Chip Green Colors 520-525nm Features


    1. Package Size:3.5(L)x2.8(W)*1.8(H)mm

    ​2. P-LCC-2 package.

    3. ​Copper base with ultra stability

    4.Wide colors: Red; Green; Blue; UV; Orange; Yellow; Amber.. Also provide 3528RG
    5. Optical indicator.
    6. Colorless clear window.
    7. Ideal for backlight and light pipe application.
    8. Inter reflector.
    9. Wide viewing angle.

    10. Suitable for automatic placement equipment.

    11. Super long lifetime:50000hrs




    3528 SMD LED Chip is the price/performance leader for commercial indoor slutions compare to the cost and efficiency. Typical PLCC-2 type white smd led, Compact SMD design with high brightnes,Consistent Color and Smooth environment, Widely apply in Decorative lighting, Light Strip,Commercial Illuminate and displays: Advertising words, light box; Garden lighting; Led back lighting; and fit for different working environment



    Specifications


    Electronic power0.06W
    ColorGreen (520-525nm)
    VF3.0-3.2V
    IF20mA
    Chip BrandSanan
    LUMINUOUS EFF7-9lm
    Chip size(mil)8*15mil


    Absolute Maximum Ratings (TA=25ºC)


    ItemSymbolAbsolute Maximum RatingUnit
    Forward CurrentIF20mA
    Pulse Forward CurrentIFP50mA
    Reverse VoltageVR5V
    Power DissipationPD100mW
    Operating TemperatureTopr-40ºC To +85ºC°C
    Storage TemperatureTstg-40ºC To +85ºC°C
    Soldering TemperatureTsld

    Reflow Soldering: 260ºC

    Hand Soldering : 350ºC

    for 10sec.

    for 3sec.


    Product Dimension(Tolerance:+/-0.1mm. Unit:mm)


    Packaging(Units:mm)


    Taping Specifications


    Reel Dimension



    3528 Smd Led Chip Application

    • High Power LED Lamp
    • Indoor lighting: Fluorescent lamp, tube
    • Commercial Illuminate and displays: Advertising words, light box
    • Decorative Lighting: Light Strip
    • Other illuminations
    • Led back lighting
