Light up the world with our “chip"
3 Years
| Ask Lasest Price | |
| Brand Name : | HuanYu Dream |
| Model Number : | HY-5730W50A85-1S |
| Certification : | Rohs |
| Price : | Negotiable |
| Payment Terms : | T/T, Paypal,Ali Pay |
| Supply Ability : | 100KKpcs/Month |
| Delivery Time : | 7-9 Work Days |
5730 High Efficiency SMD Chip LED 200LM/W at 150mA 0.5W
HuanYu dream Mid-power 0.5w 5730 smd led offers super luminous efficacy 190-200lm/w at rated 150mA, which are the enviromental and economical light source solution for general lighting. Good quality material ensures high reliablity and long serving time.
Features
Specification
| Current | voltage | CCT | CRI | TYP Flux (lm) | Efficiency | Part number |
150mA | 2.8-3.0V | 5000K | 80 | 80-85lm | @60mA, up to 180-190lm/w | HY-5730W50A85-1S |
NOTE:
70Ra/90Ra/95Ra/98Ra is Available
CCT can be changable, such as 3000K,4000K, 6000K and others
Electrical - Optical Characteristics at Ta=25℃
| Type | Symbol | Test condition | Value | Unit | ||
| Min. | Typ. | Max. | ||||
| Forward Voltage | VF | IF=150mA | 2.8 | -- | 3.0 | V |
| 6000K-7000K | φ | IF=150mA | 80 | 85 | Lm | |
| Reverse Current | IR | VR=5V | -- | -- | 1 | uA |
| Viewing Angle | 2θ1/2 | IF=150mA | 120 | Deg | ||
| Color Rendering Index | CRI | IF=150mA | 80 | -- | 83 | -- |
| Thermal resistance | Rth(j-s) | IF=150mA | -- | -- | 28 | ℃/W |
Test report
@60mA
@150mA
Measurement
Package Specifications
(1)The LEDs are packed in carboard boxes after taping
(2)Taping Specification(units:mm)
(3) Reel Dimension
Package:4000Pcs/Reel
FAQ
Q1. Do you have any minimum order quantity (MOQ) for LED light orders? What is the payment method?
A: The MOQ for each model is 100pcs. We accept T/T, PayPal, and Western Union as payment methods.
Q2. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx, or TNT. It usually takes 2-5 days to arrive. We also offer airline and sea shipping as options.
Q3.Can I place an order for LED lights?
A: Yes, we are happy to accept sample orders for LED lights to test and verify quality. Mixed samples are acceptable.
Q4. What is the lead time for LED light orders?
A: The lead time for samples is 1-3 days, and it takes 3-7 days for mass production depending on the order quantity.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places
Q6. How do I handle a faulty product?
A: Our products are produced under strict quality control system, and the defective rate is less than 0.2%. If you receive a faulty product, please first contact us and provide us with the fault details. We will send you a new product within the guarantee period.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: Is it allowed to print my logo on the LED light product?
A: Yes, it is allowed. Please inform us in advance before production, and we will confirm the design with you based on our sample.
|
|
